printed circuit board (pcb) design program - GTK+ interface

Description

PCB is an interactive printed circuit board editor for the X11 window system. PCB includes a rats nest feature, design rule checking, and can provide industry standard RS-274-X (Gerber), NC drill, and centroid data (X-Y data) output for use in the board fabrication and assembly process. PCB offers high end features such as an autorouter and trace optimizer which can tremendously reduce layout time.

This package contains the GTK+ user-interface for pcb.
