transcalc

microwave and RF transmission line calculator

Description

Transcalc is an analysis and synthesis tool for calculating the electrical and physical properties of different kinds of RF and microwave transmission lines.

For each type of transmission line, using dialog boxes, you can enter values for the various parameters, and either calculate its electrical properties (analyze), or use the given electrical requirements to synthesize physical parameters of the required transmission line.

Available transmission lines (this list will expand with subsequent releases): Microstrip, Rectangular Waveguide.
