dxf2gcode

prepares drawings of parts for automatic machine tools

Description

This program reads 2D mechanical drawings of parts to be fabricated and produces G-code tool movement instructions for running on automatic machine tools (CNC machines) such as milling machines and lathes.

This is a graphical CAM (Computer Aided Manufacturing) program. It accepts input in DXF, PDF, or Postscript format. It supports milling, drilling, and turning operations, as well as work-holding tabs.
