msc-generator

Draws signalling charts from textual description

Description

Msc-generator is a program that parses textual Message Sequence Chart descriptions and produces graphical output in a variety of file formats.

Msc-generator heavily borrows in concept from the 0.08 version of Michael C McTernan's mscgen. However, it has been completely rewritten from scratch and has a much more extensive (and only partially backwards compatible) language. The command-line interface is fully backwards compatible with mscgen, which enables using Msc-generator's commandline tool everywhere where you can use mscgen, but with the richer syntax. This includes the many tools integrated with mscgen, such as Doxygen, Sphinx and Msctexen.

Upload more screenshots

Please help extend the collection of screenshots. Just make a screenshot and upload it here. You don't need to register or anything.

Upload a screenshot

Hint: upload an image here from your clipboard with Ctrl-V


Homepage

https://gitlab.com/msc-generator/msc-generator
