printed circuit board (pcb) design program - meta-package

printed circuit board (pcb) design program - meta-package
from version 20110918-9
solder layer png
solder layer png
from version 20110918-4
printed circuit board (pcb) design program - meta-package
from version 20080202-2

Description

PCB is an interactive printed circuit board editor for the X11 window system. PCB includes a rats nest feature, design rule checking, and can provide industry standard RS-274-X (Gerber), NC drill, and centroid data (X-Y data) output for use in the board fabrication and assembly process. PCB offers high end features such as an autorouter and trace optimizer which can tremendously reduce layout time.
