solvespace

Parametric 2d/3d CAD

Description

SolveSpace is a parametric 2d/3d CAD program. Applications include:

 * modeling 3d parts — draw with extrudes, revolves, helix creation,
   and Boolean (union / difference / intersection) operations;
 * modeling 2d parts — draw the part as a single section, and export DXF,
   PDF, SVG; use 3d assembly to verify fit;
 * 3d-printed parts — export the STL or other triangle mesh expected by
   most 3d printers;
 * preparing CAM data — export 2d vector art for a waterjet machine or
   laser cutter; or generate STEP or STL, for import into third-party
   CAM software for machining;
 * mechanism design — use the constraint solver to simulate planar or
   spatial linkages, with pin, ball, or slide joints;
 * plane and solid geometry — replace hand-solved trigonometry and
   spreadsheets with a live dimensioned drawing.
